Abrasive-Resistant (AR) Plates
Plate and Sheet
AR (Abrasion Resistant) Steel Plates are durable quenched and tempered alloy steel plates, with the "F" standing for "Formable." Available in several levels of Brinell Hardness with 400F, 450F & 500F. Available in standard stock dimensions, cut-to-size dimensions, and custom part orders
1 2
Item # |
Thickness (in) |
Weight Per Square Foot (lb) |
Grade |
Material |
Finish |
Request Quote |
|---|---|---|---|---|---|---|
| 3/16 AR 400F PLATE 3/16 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 3/16 | Weight Per Square Foot (lb) N/A 7.646 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1/4 AR 400F PLATE 1/4 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1/4 | Weight Per Square Foot (lb) N/A 10.21 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 5/16 AR 400F PLATE 5/16 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 5/16 | Weight Per Square Foot (lb) N/A 12.75 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/8 AR 400F PLATE 3/8 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 3/8 | Weight Per Square Foot (lb) N/A 15.307 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1/2 AR 400F PLATE 1/2 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1/2 | Weight Per Square Foot (lb) N/A 20.405 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 5/8 AR 400F PLATE 5/8 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 5/8 | Weight Per Square Foot (lb) N/A 25.502 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/4 AR 400F PLATE 3/4 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 3/4 | Weight Per Square Foot (lb) N/A 30.6 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1 AR 400F PLATE 1 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1 | Weight Per Square Foot (lb) N/A 40.81 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1 1/8AR 400F PLATE 1 1/8AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1-1/8 | Weight Per Square Foot (lb) N/A 45.94 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1 3/16 AR 400F PLATE 1 3/16 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1-3/16 | Weight Per Square Foot (lb) N/A 48.51 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1 1/4 AR 400F PLATE 1 1/4 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1-1/4 | Weight Per Square Foot (lb) N/A 51.12 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1 1/2 AR 400F PLATE 1 1/2 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 1-1/2 | Weight Per Square Foot (lb) N/A 61.2 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 2 AR 400F PLATE 2 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 2 | Weight Per Square Foot (lb) N/A 81.677 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 2 1/2 AR 400F PLATE 2 1/2 AR 400F PLATE/Asset/Plates.png | Thickness (in) N/A 2-1/2 | Weight Per Square Foot (lb) N/A 102.01 | Grade N/A AR400F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/16AR 450F PLATE 3/16AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A -3/16 | Weight Per Square Foot (lb) N/A 7.646 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1/4 AR 450F PLATE 1/4 AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A 1/4 | Weight Per Square Foot (lb) N/A 10.21 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/8 AR 450F PLATE 3/8 AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A 3/8 | Weight Per Square Foot (lb) N/A 15.307 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1/2 AR 450F PLATE 1/2 AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A 1/2 | Weight Per Square Foot (lb) N/A 20.405 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 5/8 AR 450F PLATE 5/8 AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A 5/8 | Weight Per Square Foot (lb) N/A 25.502 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/4 AR 450F PLATE 3/4 AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A 3/4 | Weight Per Square Foot (lb) N/A 30.6 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1 AR 450F PLATE 1 AR 450F PLATE/Asset/Plates.png | Thickness (in) N/A 1 | Weight Per Square Foot (lb) N/A 40.81 | Grade N/A AR450F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/16 AR 500F PLATE 3/16 AR 500F PLATE/Asset/Plates.png | Thickness (in) N/A 3/16 | Weight Per Square Foot (lb) N/A 7.646 | Grade N/A AR500F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1/4 AR 500F PLATE 1/4 AR 500F PLATE/Asset/Plates.png | Thickness (in) N/A 1/4 | Weight Per Square Foot (lb) N/A 10.21 | Grade N/A AR500F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 3/8 AR 500F PLATE 3/8 AR 500F PLATE/Asset/Plates.png | Thickness (in) N/A 3/8 | Weight Per Square Foot (lb) N/A 15.307 | Grade N/A AR500F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
| 1/2 AR 500F PLATE 1/2 AR 500F PLATE/Asset/Plates.png | Thickness (in) N/A 1/2 | Weight Per Square Foot (lb) N/A 20.405 | Grade N/A AR500F | Material N/A Alloy Steel | Finish N/A Bare | Request Quote |
